TINOX TPW-716 Hybrid Titanium Dioxide Pigment with Brightness L* ≥97.0 and Dispersibility Hegman Scale ≥6.5 for High-Performance Coatings

All Category

Chloride Process Titanium Dioxide

Sulphate Process Titanium Dioxide

Alcohol Ester

Ms. Lena Yuan

Lena@tinoxchem.com

+86 19382116004

Contact Now

TINOX TPW-716 Hybrid Titanium Dioxide Pigment with Brightness L* ≥97.0 and Dispersibility Hegman Scale ≥6.5 for High-Performance Coatings

Brand Name:	TINOX
Model Number:	TPW-716
MOQ:	20MT
Price:	Negotiable
Packaging Details:	25KG/BAG
Payment Terms:	L/C,T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

REACH

Brightness L*(powder):

≥97.0

B* (powder):

≤ 1.8

Rel. Humidity (105C°):

≤ 0.5

D50 (µm):

Bulk Density(kg/m³):

Post Treatment:

Al, Zr, P, Organic

PH-value:

6.5-8.5

Dispersibility Hegman Scale:

Supply Ability:

Excellent

Highlight:

high-performance titanium dioxide pigment

titanium dioxide pigment for coatings

superior paint titanium dioxide pigment

Product Description

TINOX TPW-716 Hybrid Technology Titanium Dioxide Pigment – High-Performance for Superior Coatings & Paint, Anti-Dumping Duty Exempt

Product Description

TINOX TPW-716 Hybrid Pigment White is a premium performance hybrid pigment for superior coatings, based on rutile-type TiO₂. Engineered specifically for high-performance paint applications, it combines premium TiO₂ pigment components with ultra-fine functional fillers through a proprietary manufacturing process.

Exceptional Performance Advantages

Superior Optical Properties Brightness L* ≥ 96.0 with bluish undertone for exceptional whiteness and visual appeal	Excellent Gloss Development Enhanced surface reflectivity and gloss stability for premium finishes
Strong Hiding Power Outstanding coverage with reduced pigment loading requirements	Enhanced Durability Improved abrasion resistance, weather resistance, and coating film hardness
Excellent Dispersion Hegman ≥ 6.5 for easy incorporation and reduced processing time	Environmental Benefits Lower CO₂ emissions per unit compared to pure TiO₂

Technical Specifications

Parameter	Value
TiO₂ content	≥74.0%
Rutile content	≥99.0%
Brightness L*	≥96.0
Oil absorption	≤20 g/100g
Relative Humidity (105°C)	≤0.5%
Post-treatment	Al, Zr, P, organic
pH value	6.5-8.5

Performance Validation

Based on comprehensive testing in the TINOX TPW Series brochure, TPW-716 demonstrates:

Whiteness index nearly matching premium TiO₂ pigment R-2160
Superior performance compared to standard TiO₂ pigment R-2140
Excellent opacity levels comparable to pure TiO₂ pigments
Outstanding gloss development for high-quality finishes

Recommended Formulation

High-Gloss Water-Based Acrylic Enamel (Based on Test Data)

Component	Function	Content (%)
Deionized Water	Solvent	18.0
Dispersing Agent	Pigment dispersion	0.6
Wetting Agent	Surface tension reduction	0.3
TINOX TPW-716	Primary pigment	22.0
Acrylic Emulsion (50%)	Binder	45.0
Coalescing Agent	Film formation	2.5
Defoamer	Foam control	0.4
Rheology Modifier	Viscosity control	0.8
Preservative	Biostability	0.2
Ammonia (28%)	pH adjustment	0.2
Water (adjustment)	Final adjustment	10.0

Processing Instructions:

Add water, dispersing agent, and wetting agent to mixing vessel
Slowly add TINOX TPW-716 under moderate agitation (800-1000 rpm)
Increase agitation speed to 1500-2000 rpm for 15-20 minutes until Hegman fineness ≥6.5 is achieved
Reduce speed and slowly add acrylic emulsion
Add coalescing agent, defoamer, rheology modifier, and preservative
Adjust pH to 7.5-8.5 with ammonia solution
Add remaining water to achieve desired viscosity
Filter and package

Expected Performance (Based on Tinox Test Data):

Whiteness Index: ≥96.5
Gloss (60°): ≥85 GU
Contrast Ratio: ≥0.98
Yellowness Index: <1.5
PVC: ~25%

Note: This formulation is based on test data from the TINOX TPW Series brochure, specifically the acrylic enamel paint tests with 75% emulsion content (PVC = 25%).

Contact Information

TINOX CHEMIE GMBH
Lutticher Straße 132, 40547 Dusseldorf, Germany
Tel: +49 (0)211 52809600

Factory Images

Factory Exterior

Lab

Certifications & Reports

REACH

SGS

ISO 9001
